Average value calculation at any given time or between two events

Nataraj Jyoti

Posted on 25.02.2019 15:21

I want to calculate average value of measured signal with below condition

  1. the last 5min of measured signal
  2. between two events in the total measured time Or between two time stamp in the log

please find the attached image for the referance


Attached files:
DEWESoft Support
Technical support
Posted on 26.02.2019 07:24

Dear Nataraj,


for the calculation of average value of the signal between two time stamps or events you can use Basic statistic with "Start-stop block" option.



For calculation the average value of the last 5 minutes of measurement we suggest the offline calculation. You can create a single value channel in Math with only acqtime for "Stop time" channel. For "Start time" channel you can only divide the 5 min from the stop channel. You can then use the channels as trigger channels in the basic statistic with "Start-stop blocks" option.



Regards

Nataraj Jyoti

Posted on 26.02.2019 09:17

Hi,

Thanks for your support but I failed to create triggers to use start and stop blocks. I have attached signal file, could you please help me to understand both way of measuring average values in the attached file.


Regards

Nataraj


Attached files:
DEWESoft Support
Technical support
Posted on 26.02.2019 13:53

Dear Nataraj,


attached is a data flle.


Regards


Attached files:
Nataraj Jyoti

Posted on 27.02.2019 07:09

Hi,

Your attchment dosn't contain right file format in order to open in DEWESoft, could you please check?

I have attached snapshot for your reference.


Attached files:
DEWESoft Support
Technical support
Posted on 27.02.2019 07:16

Dear Natraj,


you just need to change the *.zip to *.dxz and than you can open the file.


Regards

Nataraj Jyoti

Posted on 27.02.2019 08:35

Hi,

I did try but not succeed, could you please share me a same file in .dxz format?

Thanks in advance.

DEWESoft Support
Technical support
Posted on 27.02.2019 10:23

Dear Natraj,


unfortunately, every *.dxz file will be transformed into *.zip file. Please see attached pictures.



Regards

DEWESoft Support
Technical support
Posted on 27.02.2019 12:58

Dear Natraj,


our developers have fixed the problem with the changing format. You can find the *.dxz file attached.


Regards


Attached files:
